R02-132-640 |
2096-07 |
PTFE Agitator, High Viscosity,
5 inch OD ① |
R02-132-634 |
2096-08 |
PTFE Agitator 19mm, High
Viscosity, 5 L용, 5.5 inch OD ① |
R02-132-636 |
2097-08 |
Stirring Shaft, 19 mm, Polished ② |
R02-132-632 |
2095-04 |
4” OD Agitator, 19 mm, 60°, PTFE ③ |
R02-132-616 |
2077-G-24 |
45/50 Stirrer Bearing, PTFE ④ |
R02-132-571 |
2044-C-16 |
Tru-Stir Stirrer Shaft Coupling, 19 mm ⑤ |
R02-132-572 |
2024-10 |
Digital Overhead Stirrer, 220V (6a) |
R02-132-579 |
2054-100 |
Velp OHS 100 Advance Stirrer, 230V (6b) |
R02-132-153 |
1929-X18 |
2000 ml Reaction Vessel, Jacketed ⑦ |
R02-132-173 |
1929-X28 |
5000 ml Reaction Vessel, Jacketed ⑦ |
R02-132-C31 |
1946-D-11 |
Lid, Reaction Vessel, 5-Neck, 150 mm ⑧ |
R02-132-624 |
141-T-14 |
150 mm Quick Release Clamp ⑨ |
R02-132-628 |
147-77 |
150 mm
O-ring, FEP-encased Stainless |
R02-132-562 |
1213-J-01 |
Condenser, Coil, Reflux ⑩ |
R02-132-567 |
1064-01 |
Adapter, Inert Gas, 24/40,
2-Hose Conn. 180° ⑪ |
R02-132-573 |
1971-M-10 |
PTFE Jacketed S.S. Baffle, 410
mm, 2 L용 ⑫ |
R02-132-577 |
1971-M-12 |
PTFE Jacketed S.S. Baffle, 515
mm, 5 L용 ⑫ |
R02-132-578 |
1971-M-20 |
24/40 Micro Baffle Adapter,
PTFE ⑬ |
R02-132-583 |
3002-L-24 |
Stopper, PTFE, 24/40 with
Loosening Ring ⑭ |
R02-132-526 |
1949-X-10 |
Reactor Support Frame and LDPE Drip Tray (16)
⑮ |
R02-132-587 |
1947-B150 |
S.S. Reactor Clamp, 150 mm (17) |
R02-132-598 |
1969-V-10 |
30 mm Flat Flange S.S Jacket Adapter (Only Manifold System) (21) |
R02-132-602 |
1949-X-13 |
Reactor Lower Support (18) |
R02-132-691 |
1949-X-1 |
Inlet + Outlet Manifold
Assembly set (17), (18) |
